Setup for 5120x800 resolution.

[baustellen]

Hey Folks,
I would like to send a signal to 4 projectors with each 1280x800 resolution.
What kind of Computer would you recommend me, for smooth playback and mixing of of native 5120x800 content?
i7-4790K,
SSD 120 GB Samsung 840 EVO
16384 MB DDR3-RAM, 1600 MHz, Micron®/Elixir®/Samsung®
NVIDIA® GeForce® GTX 750 Ti, 2048 MB GDDR5, VGA, DVI, HDMI, inklusive NVIDIA® GeForce Experience™

Could this guy handle it?

[gabonacorp]

without a problem. but you have 4 outputs from the card and the gui takes one so I suggest you a Datapath X4 with a 2560x1600 resolution (2x2) and a 1280x800 comp size. yo can put every projector's content into different layers and arrange them with the advanced output.

[baustellen]

Ah, right. But the Datapath seems quite pricey to me.
If I use a second, cheap, very simple graphic Card and use this one for the GUI. Is this possible?
Because, that would save a lot of money.

[drazkers]

Ah, right. But the Datapath seems quite pricey to me.
If I use a second, cheap, very simple graphic Card and use this one for the GUI. Is this possible?
Because, that would save a lot of money.

Get a matrox triplehead instead. Less potential issues and you don't loose performance, your already pushing it with a 750. I'd go with a 760.

[Oaktown]

I have had very good luck driving up to 6 screens (1 monitor and 5 projectors) with the AMD hd 5870 eyefinity 6 which is quite affordable. If you go that route, just make sure you use all active adapter.

[Zoltán]

Ah, right. But the Datapath seems quite pricey to me.
If I use a second, cheap, very simple graphic Card and use this one for the GUI. Is this possible?
Because, that would save a lot of money.

The card running the GUI will do the rendering.(primary display adapter)
You could try the other way around, using a cheaper card for extra outputs.

[mrfipe]

Hello,

I use a regular setup, with one Nvidia 760 4GBRAM with one or two matrox triple head and 2 SSD kingston V300 in raid 0, and I get good results over 60fps

This weekend I used a machine with two Nvidia 760 4GBRAM to do a resolution of 4800x1400 pixels and 5 outputs (4 projectors and 1 led screen) and every thing went well.
(I only used two cards because I do not have the matrox to use, they were in other works)
2 projectors output 1920x1080
2 projectors output 1024x768
1 led screen output 1920x1080
UI screen 1920x1080

[Oaktown]

Baustellen, driving 4 projectors at 5120*x800 + main UI should be no problems how many layers will your composition be?
